Parent Layer: USGS County Boundary

Name: USGS County Boundary

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The West Virginia State Code states that the boundary lines between the counties of the state are sourced from the U.S. Geological Survey (USGS) (1:24,000 scale) topographic quadrangle maps. The West Virginia Department of Environmental Protection (WVDEP) digitized county boundary lines off of USGS 1:24,000-scale Digital Raster Graphics (DRG, scanned topographic maps), and published the "24k" county boundary in January 2002.</SPAN></P><P><SPAN /></P><P><SPAN>County boundary lines rarely change, and any changes made will be only as a result of court orders or similar actions by similar authorities. The Circuit Court of Lincoln County handed down such an order in April of 2016. A formerly straight portion of the boundary between Lincoln and Logan counties near Harts, WV now follows the low water mark of the Guyandotte River between 38.007447 N, 82.071527 W, and 38.009450 N, 82.064067 W.</SPAN></P><P><SPAN /></P><P><SPAN>The WVGISTC revised the Lincoln / Logan GIS boundary features in 2022 according to the court order of 2016 and including the two reference points stated in the order. The WVGISTC also reviewed the boundaries of all 55 WV counties and corrected areas of significant deviation from the "24K" DRG boundary lines.</SPAN></P></DIV></DIV></DIV>

Copyright Text: U.S. Geological Survey, WV Department of Environmental Protection, West Virginia GIS Technical Center

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 577790.554289

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -9199945.4119
YMin: 4467223.369400002
XMax: -8651646.6784
YMax: 4959211.283799998
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [130, 130, 130, 0]
Outline:
Style: esriSLSDashDot
Color: [52, 52, 52, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 30
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [78, 78, 78, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: baseline
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• County_Name ( type: esriFieldTypeString, alias: County_Name, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• NAME ( type: esriFieldTypeString, alias: NAME, length: 15 )
• StCoFIPS ( type: esriFieldTypeString, alias: StCoFIPS, length: 5 )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
